Grounding Clip Solar

Grounding Clip Solar specifically includes a main plate, a side pressure plate, a U-shaped hole, an upper puncture column and a lower puncture column, characterized in that the main plate is shaped as an “I”, there is a U-shaped hole in the middle of the main plate, there are two rectangular openings on the left and right sides of the main plate, and there are two rectangular side pressure plates at the rectangular openings, and the rectangular side pressure plates are vertically downwardly facing the main plate, and there are upper puncture columns and lower puncture columns at the top and bottom parts of the rectangular openings, respectively. Vertical downward, the upper and lower parts of the rectangular openings are equipped with upper puncture columns and lower puncture columns, upper puncture columns and lower puncture columns, respectively, vertically on the top and bottom of the main board, the photovoltaic module frame is an aluminum alloy frame, the two photovoltaic modules are fixed by the pressure block, the utility model is embedded in the grooves of the aluminum guide rail and fasteners and fixed with the pressure block connection, the upper puncture columns puncturing the photovoltaic module along the lower edge of the aluminum alloy frame of the oxidation film, and at the same time, the lower puncture columns puncture the aluminum guide rail. After the upper puncture column punctures the oxide film on the upper edge of the aluminum rail, the two components are connected into a pathway and effectively connected to the aluminum rail, which is connected to the original building’s lightning protection grounding strip, thus realizing the lightning protection and grounding of photovoltaic modules.
